Bus 9m

Discover the 9m electric bus: eco-friendly, with ample seating and high-performance battery technology for smooth city and intercity journeys.

1 5

Key Features

  • Seating Capacity - 39+1+1

  •

    Bus Size - 9.5m(L) x 2.5m(W) x 3.6m(H)

  •

    Range on Full Charge > 400km
Make an enquiry

Specification

    1 0
    Feature Value
    Vehicle Dimensions 9495 (L) x 2530 (W) x 3595 (H) mm
    Wheelbase 4500 mm
    Motor DANA, PMSM
    Battery Pack Lithium Iron phosphate, 282 kWh, CATL
    Front/Rear Overhang 2085/2910 mm
    Front/Rear Tread 2105/1886 mm
    Angle of Approach/Departure 9/11 °
    Curb Weight 11500 kg
    Maximum Total Mass 16500 kg
    Axle Load 5,500/ 11,000 kg
    Maximum Passengers 39 Seats + 1 Driver + 1 Wheelchair
    Maximum Speed 100 km/h
    Cruise Mileage (Fully Loaded) 400 km
    Maximum Gradability 20%
    Minimum Ground Clearance ≥ 120 mm
    Minimum Turning Radius 16 m
